Aircraft › Lockheed Martin › Lockheed Martin F-22 Raptor › Lockheed Martin F-22A Raptor
Lockheed Martin F-22A Raptor
The F-22A is flown by one pilot. Two Pratt and Whitney F119-PW-100 turbofans, each in the 35,000-pound class and fitted with two-dimensional thrust-vectoring nozzles, let it supercruise, flying faster than Mach 1.5 without afterburner. The Air Force quotes a speed of Mach 2 class, a ceiling above 50,000 feet and a ferry range of more than 1,850 miles, 1,600 nautical miles, with two external wing tanks. In the air-to-air load it carries six AIM-120 and two AIM-9 missiles inside the aircraft. The Air Force declared initial operating capability in December 2005.
- Range
- 1,840 miles (1,600 nm, 2,960 km) unrefueled
- Engines
- Two Pratt and Whitney F119-PW-100 turbofans in the fuselage
- Max takeoff weight
- 83,500 lb (37,875 kg)
Photos from members
No member photos of this aircraft yet. Be the first to add one.
Specifications
| Length | 62 ft 1 in (18.92 m) |
|---|---|
| Wingspan | 44 ft 6 in (13.56 m) |
| Height | 16 ft 8 in (5.08 m) |
| Ceiling | 50,000 ft (15,200 m) |
| Entry into service | December 2005 |
| Status | In service |
| Type codes | ICAO F22 |
Who flies it
- US Air Force (Air Combat Command, Pacific Air Forces and Air Education and Training Command)
Service branches, from the services' own fact sheets. No flight data is shown for military aircraft.
