Aircraft › Boeing › Boeing 787 Dreamliner › Boeing 787-10

Boeing 787-10

The 787-10 is the longest 787, 224 ft 1 in, a further 18 feet longer than the 787-9 on the same wing and fuel tanks. Boeing's planning layout seats 330 in two classes, 32 in business and 298 in economy, and 440 in economy only, which is also its exit limit. It trades range for seats: Boeing quotes up to 7,500 nautical miles, and its maximum operating altitude is 41,100 feet against 43,100 for the smaller 787s. It takes off at up to 574,000 pounds and flies with General Electric GEnx-1B or Rolls-Royce Trent 1000 engines.

Range: 8,630 miles (7,500 nm, 13,890 km)
Seats: About 330 in two classes (up to 440)
Engines: Two General Electric GEnx-1B or Rolls-Royce Trent 1000 turbofans under the wings
Max takeoff weight: 574,000 lb (260,362 kg)

Boeing 787-10 — Photo: Danny Yu, CC BY-SA 4.0

Boeing 787-10 seen from above: length 224 ft 1 in (68.30 m), wingspan 197 ft 3 in (60.12 m) — Drawings: cwsi.net, from published dimensions (schematics, not to exact detail)

Boeing 787-10 seen from the side: height 55 ft 10 in (17.02 m) — Drawings: cwsi.net, from published dimensions (schematics, not to exact detail)

Photos from members

No member photos of this aircraft yet. Be the first to add one.

Specifications

Length	224 ft 1 in (68.30 m)
Wingspan	197 ft 3 in (60.12 m)
Height	55 ft 10 in (17.02 m)
Fuselage width	18 ft 11 in (5.77 m)
Ceiling	41,100 ft (12,500 m)
Fuel capacity	33,400 US gal (126,429 L)
Status	In service
Type codes	ICAO B78X
