Aircraft › ATR › ATR 42 › ATR 42-600

ATR 42-600

The ATR 42-600 is the current version of the 42. ATR gives it 48 seats at 30-inch pitch as standard and up to 50, with a maximum take-off weight of 18,600 kg. Two Pratt and Whitney Canada PW127XT-M engines of 2,400 shaft horsepower turn six-blade Hamilton Standard propellers 3.93 meters across. ATR quotes a maximum cruise speed of 289 knots true airspeed and a range of 747 nautical miles with a full cabin at long-range cruise speed. The airplane is 22.67 meters long, has a wingspan of 24.57 meters and stands 7.59 meters high.

Range
860 miles (747 nm, 1,380 km)
Cruise speed
289 knots (540 km/h)
Seats
48 in one class (up to 50)
Engines
Two Pratt and Whitney Canada PW127XT-M turboprops on the wings
Max takeoff weight
41,000 lb (18,600 kg)
ATR 42-600
Photo: ATR Aircraft, CC BY-SA 2.0
ATR 42-600 seen from above: length 74 ft 5 in (22.67 m), wingspan 80 ft 7 in (24.57 m)
Drawing: cwsi.net, from published dimensions (a schematic, not to exact detail)

Photos from members

No member photos of this aircraft yet. Be the first to add one.

Specifications

Length74 ft 5 in (22.67 m)
Wingspan80 ft 7 in (24.57 m)
Height24 ft 11 in (7.59 m)
StatusIn service
Type codesICAO AT46
