Piper PA-28R Cherokee Arrow, Arrow II, III and IV
The Arrow is the retractable-gear PA-28: the PA-28R-180 (approved in 1967), the PA-28R-200 Arrow and Arrow II, the PA-28R-201 Arrow III and the PA-28RT-201 Arrow IV, which added a T-tail with a stabilator in the 1979 model year. The figures here are the Arrow IV's: a 200 hp Lycoming IO-360-C1C6, a maximum weight of 2,750 pounds and 77 US gallons of fuel in two wing tanks, of which 72 are usable. ICAO code P28R covers the first four models and P28T the Arrow IV.
- Seats
- About 4
- Engines
- One piston engine in the nose: Lycoming IO-360-C1C6
- Max takeoff weight
- 2,700 lb (1,247 kg)
Photos from members
No member photos of this aircraft yet. Be the first to add one.
Specifications
| Fuselage width | 3 ft 7 in (1.10 m) |
|---|---|
| Fuel capacity | 70 US gal (273 L) |
| Status | In service |
| Type codes | ICAO P28R, P28T |
Private aircraft show specs only. No flight data is shown for them.
