Beechcraft Bonanza G36
The G36, approved by the FAA in 2005, is the Bonanza 36 with a Garmin G1000 glass cockpit and a 300 hp Continental IO-550-B. The figures are from the FAA and EASA data sheets and Textron Aviation's specifications: a maximum weight of 3,805 pounds in the normal category (3,650 pounds in the utility category), 74 US gallons of usable fuel, a maximum operating altitude of 18,500 feet and a maximum cruise speed of 174 knots true airspeed. It seats six.
- Cruise speed
- 174 knots (320 km/h)
- Seats
- About 6
- Engines
- One piston engine in the nose: Continental IO-550-B
- Max takeoff weight
- 3,800 lb (1,726 kg)
Photos from members
No member photos of this aircraft yet. Be the first to add one.
Specifications
| Length | 27 ft 6 in (8.38 m) |
|---|---|
| Wingspan | 33 ft 6 in (10.21 m) |
| Height | 8 ft 7 in (2.62 m) |
| Fuselage width | 3 ft 11 in (1.20 m) |
| Ceiling | 18,500 ft (5,600 m) |
| Fuel capacity | 70 US gal (280 L) |
| Status | In service |
| Type codes | ICAO BE36 |
Private aircraft show specs only. No flight data is shown for them.
